Free to use No sign-up Built from published standards

Reference sheets for the workshop

The chart you need. Ready to print.

Easy-to-read reference charts for the bench, toolbox and jobsite.

View charts on your phone or print a copy for your workbench. Sources and conditions are included on every sheet.

Wire gauge chart listing every AWG size from 4/0 to 40 with conductor diameter in inches and millimeters and cross-sectional area in mm².

Sources mapped to columns

See where the values come from, with sources listed for each column.

Date last checked

Every chart shows when its values were last checked.

Print, PDF, PNG

Print a sheet for the wall, save a PDF or download a PNG. Wide tables use landscape layouts to keep the numbers readable.

Charts on the site

5 free reference charts, ready to use.

Browse by trade

Find reference sheets for the work you do.

Know where the numbers come from.

Sources per column

Different columns may use different sources. Each chart lists the documents and definitions used, along with the columns they cover.

Checked before publication

Calculated values are checked against their formulas. Values taken from standards are compared with the original tables before publication.

Conditions on the sheet

Temperature, plating and lubrication can affect the values you need. Relevant conditions appear on both the page and the printed sheet.

Example Wire size alone does not determine ampacity Use the wire gauge chart for dimensions and the ampacity chart for current ratings, including the conditions in NEC 310.16 and limits in 240.4(D).

Outfit your shop class.

Free printable sheets that name their standards, so students can see where a number comes from. Sized for handouts, stations and classroom walls.

Browse classroom sheets →
